감응작용 놋쇠로 만들기 기계
>
|
| Place of Origin | CHINA |
| 브랜드 이름 | ZHENGZHOU LANSHUO |
| 인증 | CE |
| Model Number | LSW-50 |
| 50KW Induction Heating Machine(LSW-50) | |
| Rated power | 50KW |
| Input voltage | Three phase electricity 380V/50-60HZ |
| DC voltage | 500V |
| DC current | 75A |
| The heating frequency | 18-25KHZ |
| Air switch | 3*100A |
| Ground wire | 1mm² copper core wire |
| Water pressure | 0.15-0.2MPa |
| Weight(after packing) | 140KG |
| Dimension(after packing) | 670mm*820mm*1460mm |
| Cooling water requirement | 2.5m³water tank or 4T closed cooling water tower |
| Electricity Installation | |
| Input power cord | 35mm² copper core wire |
| Input power control switch | 3*150A |
| Equipment ground wire | 1mm² copper core wire |
| Cooling water installation | |
| Control cabinet water interface quantity | water inlet:one water outlet:one |
| Auxiliary engine water interface quantity | water inlet:one water outlet:one |
| Water pipe specification | connecting equipment water intake pipe:internal diameter 25mm |
| Connecting equipment water outtake pipe:internal diameter 25mm | |
